Building Material Shops Hydraulic Hose Machine Pressing Automatic Hose Machine High Pressure Hydraulic Rubber Hose Crimping Portable Crimping Mac

1 Piece
MOQ
Building Material Shops Hydraulic Hose Machine Pressing Automatic Hose Machine High Pressure Hydraulic Rubber Hose Crimping Portable Crimping Mac
Caracteristicas Galería Descripción de producto Pida una cita
Caracteristicas
Especificaciones
Condition: New
Video outgoing-inspection: Provided
Machinery Test Report: Provided
Marketing Type: Hot product 2021
Warranty of core components: 1 Year
Core Components: PLC, Engine, Bearing, Gearbox, Pressure vessel, Gear, Pump
Machine Type: Hose Crimping Machine
Voltage: 12V/24V
Dimension(L*W*H): 600*460*500mm
Weight: 150KGS
Warranty: one year
Power (kW): 3KW
Key Selling Points: Easy to Operate
Showroom Location: Egypt, Canada, Turkey, United Kingdom, United States, Italy, France, Germany, Mexico, Colombia, Sri Lanka, Japan, Malaysia, Australia
Applicable Industries: Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Retail, Construction works , Energy & Mining
Product Name: high pressure hose crimping machine
Crimping range: 3-61mm(1/8"-2 3/8")
Max Hydraulic Hose: 1 1/2" ,4SP (ID 38mm)
Max Opening: +21mm(5/6")
Opening without Dies: 96mm ( 3 4/5")
Master Die Length: 70mm( 2 3/4")
Sytem Pressure: 31.5Mpa
Max .Crimping Force: 1750KN(175T)
Standard Voltage: 12V/24V
Control: Automtic
After Warranty Service: Video technical support, Online support, Spare parts
Local Service Location: None
Certificación: CE,ISO9001:2000;IATF16949
Información básica
Certificación: CE,ISO9001:2000;IATF16949
Pago y Envío Términos
Packaging Details: 700(L) * 560 (W) * 600 (H) packed in wooden carton
Descripción de producto
Product Description
Specification
item
Hydraulic hose machine pressing automatic hose crimping machine
Place of Origin
China
Condition
New
Video outgoing-inspection
Provided
Machinery Test Report
Provided
Marketing Type
Hot product 2021
Warranty of core components
1 Year
Core Components
PLC, Engine, Bearing, Gearbox, Pressure vessel, Gear, Pump
Brand Name
QDGY
Machine Type
Hose Crimping Machine
Voltage
12V/24V
Dimension(L*W*H)
600*460*500mm
Weight
150KGS
Certification
CE,ISO9001:2000;IATF16949
Warranty
one year
Power (kW)
3KW
Key Selling Points
Easy to Operate
After Warranty Service
Video technical support, Online support, Spare parts
Local Service Location
None
Showroom Location
Egypt, Canada, Turkey, United Kingdom, United States, Italy, France, Germany, Mexico, Colombia, Sri Lanka, Japan, Malaysia, Australia
Applicable Industries
Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Retail, Construction works , Energy & Mining
Product Name
high pressure hose crimping machine
Crimping range
3-61mm(1/8"-2 3/8")
Max Hydraulic Hose
1 1/2" ,4SP (ID 38mm)
Max Opening
+21mm(5/6")
Opening without Dies
96mm ( 3 4/5")
Master Die Length
70mm( 2 3/4")
Sytem Pressure
31.5Mpa
Max .Crimping Force
1750KN(175T)
Standard Voltage
12V/24V
Control
Automtic

Machine Head

Attribute: Forge Steel
Original: Germany Technology
Front cover, cylinder and piston use Chrome40, forging integrity, increase its fatigue resistance. Surface hardness is HRC26-30°,
hardness of inside layer is HRC59-63°, Eht 2mm.

Dies & Mold Base

Attribute: Strong Magnetic Connection
Original: QDGY(Patented)
Use Cr12 standard die steel which is a classical alloy tool steel, domestic implementation standard is GB/T 1299-2000. Dies and
die base is connected by cutting-the-edge technology of strong magnetic connection, for which our company holds the patent.

Power System

Attribute: DC Power Supply
Original: China(Mainland)
YONG-FENG Y32V crimp press for ocean hoses is very popular in the industry of mobile service. This kind of power system can
provide stable power supply for the machine, and makes the crimper more convenient for outdoor work.
Control Panel
Attribute: Simple Operated
Original: China(Mainland)
The power system was controlled by a control panel. There are three buttons and a indicator on the panel, simple design makes the
controls and operation very easy.
Packing & Delivery

Packing
Size
700(L) * 560 (W) * 600 (H)
Weight
155kgs
Packaging Details
The normal package for our crimping machine is Wooden Plywood Crate. The outside package is standard export wooden case, and the
inner package is stretch film or packaged according to customers special request.
Company Profile
Qingdao Guosong Machinery Parts Co., Ltd. was founded in 1998. Our company has been expanded to the leading brake hose manufacturer in China. We have more than 300 staff members. Our building covers 6,000 square meters. We have Marketing Department, a Hose Factory and a Fitting Factory. Our main products are QDGY brand rubber brake hoses (3.2mmx10.5mm) which are produced according to American standards SAEJ1401 and also passed the quality test of China National Auto Testing. We get DOT certification. Our company has ISO9001:2000 and TS16949:2009 quality management system certifications. To provide our customers with the best products at the most reasonable price, we are ready to do innovation. We have imported modern production lines from Japan and adopted American and Italian techniques and skills. Our senior scientific and technological experts, advanced R&D Lab and testing equipment make our products perfect. Our QDGY brake hoses, hose assembly and fittings are manufactured with a variety of superior materials to meet various requirements of Automobile and Motorcycle Industries, especially in aftermarket. They are used in ISUZU, SUZUKI, YAMAHA, KAWA-SAKI, HONDA, MITSUBISHI, NISSAN, TOYOTA, ALTO, FLAT, FORD, CHRYSLER, CHEROKEE, AUDI, PEUGEOT, BMW, VW, IVECO, CHEVROLET, CITROEN and VOLVO cars. 90% of our products are exported to Europe, the USA and Southeast Asia. We have won a high reputation among clients. Our mission is continuously improving the quality of our products and sales service to make QDGY brand become one of the most famous brands in the world. You're welcome to visit our homepage to learn about our company and our products. For any further information, our staff members will reply you immediately. You are welcome to contact us now and get more benefits.
FAQ
1. who are we?
We are based in Shandong, China, start from 1998,sell to North America(15.00%),South Asia(13.00%),Northern Europe(12.00%),Eastern Europe(12.00%),Oceania(10.00%),Central America(10.00%),Domestic Market(9.00%),Western Europe(6.00%),Africa(5.00%),Mid East(2.00%),South America(2.00%),Eastern Asia(2.00%),Southern Europe(1.00%),Southeast Asia(1.00%). There are total about 101-200 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Brake Hose,Brake Hose Assembly,Brake hose Fitting,Nylon Stainless Steel Braided Brake Hose,Teflon Stainless Steel Braided Brake Hose

4. why should you buy from us not from other suppliers?
QDGY is established in 1998 QDGY have more than 20 years production and sale experience for OEM QDGY products are exported more than 60 countries QDGY get ISO9001,TS16949,DOT certificate Products quality and delivery in timeis the fist in QDGY

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF;
Accepted Payment Currency:USD;
Accepted Payment Type: T/T,L/C,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
How to contact us
Push Contact us ,contact on alibaba ,
or by email or send inquiry to us ,we wait for you 24 hours
